Technical Specifications – Musikfest Café
Director of Production
Michael Liiro
mliiro@artsquest.org
Production Manager
Scott Dean
sdean@artsquest.org
Production Technical Coordinator
Grace Mack
gmack@artsquest.org
Sound
Consoles:
- FOH – Digico SD12 w/Waves soundgrid (Nov-March), Avid Profile (March-Oct)
- MON – Digico SD12 OR Avid SC48 w/ISO XLR split located SL
Speakers:
- 22 powered Renkus Heinz PNX102LA-double 10 inch array boxes split into 4 arrays for maximum room coverage.
- 4 Dual 15-inch passive flown subs.
- 2 Dual 15-inch passive floor subs
- 7 Renkus Heinz front fill speakers
- 4 JBL 2-way balcony fill speakers.
- 12 Renkus Heinz PF1-200 12 inch monitors.
Processing:
- Harmen/London/BSS Processing and distribution. Analogue and/or AES I/O
- 4 analogue inputs or 4 digital AES inputs to control
Misc notes:
- For analogue consoles safe snake run from stage to FOH is 250 feet.
- Monitor world is stage left.
- 1 CAT6 (audio) available to FOH
- 2 CAT5 (data only) available to FOH
Lighting
Console:
- Avolites Arena with Titan Software
- Lighting console located on 4th floor overlooking stage
Moving lights:
- 4 (four) High End Solaspot Pro CMY LED
- 4 (four) Martin Mac Aura LED
Hazer:
- DF50 DMX
Misc notes:
- 26 foot scissor lift available for focus
- Lighting grid can be raised and lowered via chain hoists
Microphones
Wired:
- 11 sm57’s
- 11 sm58’s
- 2 AKG 414
- 4 KSM 137
- 4 beta 98’s
- 2 sm81’s
- 3 beta 52A
- 2 beta 91A
- 4 Audix D2
- 4 beta 56A
- 4 beta 57A
- 3 beta 87A
- 3 mx412
- 4 md421
- Four 604s
- Three 609s
- Ample XLR cables and microphone stands
DI:
- 4 duplex passive stereo radial di
- 4 passive JDI radial di
- 7 active j48’s radial di
- 4 whirlwind iso 1
Wireless mics:
- 3 countryman
- 3 wireless 93 lavaliere
- 3 ULX sm87’s wireless
- 3 ULX wireless packs
- 6 ULX receivers
- 4 URD sm58’s
- 4 URD packs
- 4 URD receivers
Backline:
- DW Drum kit, 22″ kick, 10″x9″ tom, 12″x10″ tom, 16″x16″ floor tom, 14″x5.5″ snare
- Fender Hot Rod Deville
- Marshall JCM 2000
- Marshall 1960b
- Roland KC-550 keyboard amp
- GK Gallien-Krueger mark 2 1001rb bass amp
- GK Gallien-Krueger 410b
- Roland RD-700 keyboard
- Key Stand & Bench
- 6 guitar stands
- 6 foot Steinway 1911 Grand Piano.
Video Projection:
- Two Vivitek DU 9800Z 18K Lumen Laser.
- Roland V-40HD Video Switcher
- 2 (two) 9×16 projection screens
House Notes:
- Stage Dimensions: 28′ wide by 20′ deep by 3 foot 9 inches tall.
- Green Room is located one floor above venue and is connected to venue by a catwalk.
- Riser packages available upon request.
- Freight elevator used to move equipment to venue floor.
- Service elevator access to all floors. Elevator dimensions: 4 foot wide opening, carriage is 8 feet long, 10 feet high.
- Maximum backdrop size 15 feet tall (truss to stage deck), by 28 feet long (stage length).
